ICESNOW Automatic control 15Ton/day Tube Ice Machine/Tube Ice Evaporator Easy Operation

Short Description:

Tube ice machine is one kind of ice machine. Because of the irregular length and hollow tube, so we called it tube ice, its inside diameter is 5 mm to 15 mm ,the length is between 25 mm ~ 42 mm, there are a variety sizes that can be chosen, the outer diameter of ice are: 22, 28,35 mm,etc. This

kind of ice is called tube ice. Tube ice is round, generous, bright and transparent, so it is welcomed by consumer, it is widely used in modulating drinks, ice beverage, decoration and food fresh keeping, etc

Send email to us

Product Detail

Product Tags

Product Features

1. Reasonable design for the framework structure with stainless steel 304, save space, and easy to install;

2. Greatly save energy, only 80-85kw powers are consumed to produce one-ton ice;

3. Ice dropping automatically, No ice dropping auxiliary equipment, lower the error rate ice outgoing;

4. Special ice outlet. Ice discharging automatically, No need taking ice by hand which can guarantee the ice clean and sanitary, meanwhile, it is matched with ice packing system to package the ice by plastic bags;

5. Equipped with Siemens PLC central program control, which allows multiple functions such as automatic machine start and shut down; Ice stopping production when the ice bins are full, Automatic water making up;

Tube Ice Machine Features

1. The evaporator using high quality stainless steel 304 and other materials processing, meet international health standards;

2. The machine adopts the integrated design, compact structure, easy installation and use;

3. PLC man-machine interface computer module, ice making and ice automatically switches off, save time and effort;

4. All equipment using CAD, 3D simulation assembly, arrangement of equipment parts and accessories, pipe to more reasonable, compact structure and not crowded, operation, maintenance more human;

5. According to different working condition of customized, non-standard machines can be made.

6. Simple structure in linear type ,easy in installation and maintain.

7. Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

8. High pressure double crank to control the die opening and closing.

9. Water-flow design, the capacity can be increased 10% higher than other similar machines.

10. Anti-dust mesh design, which is removable and easy for cleaning.

11. Oval design of the edges, enhanced durable machine body and 304 stainless steel material design.

Technical Parameter

Model		ISN-TB10		ISN-TB20		ISN-TB30	ISN-TB50	ISN-TB100	ISN-TB150	ISN-TB200	ISN-TB300
Capacity (Tons/24hrs)		1		2		3	5	10	15	20	30
Refrigerant		R22/R404a/R507
Compressor Brand		Bitzer/ Hanbell
Cooling Way		Air Cooling			Air/Water Cooling				Water Cooling
Compressor Power		4	9		14(12)		28	46(44)	78(68)	102(88)	156(132)
Ice Cutter Motor		0.37	0.37		0.55		0.75	1.1	2.2	2.2	2.2
Power of Circulating Water Pump		0.37	0.37		0.55		0.75	1.5	2.2	2.2	2*1.5
Power of Water Cooling Pump					1.5		2.2	4	4	5.5	7.5
Cooling Tower Motor					0.55		0.75	1.5	1.5	1.5	2.2
Ice Machine Size	L (mm)	1300	1650		1660/1700		1900	2320/1450	2450/1500	2800/1600	3500/1700
	W (mm)	1250	1250		1000/1400		1100	1160/1200	1820/1300	2300/1354	2300/1700
	H (mm)	1880	2250		2200/2430		2430	1905/2900	1520/4100	2100/4537	2400/6150

1. Human consumption ice plant

2. Port ice plant

3. Coffee shop, bar, and hotel etc

4. Supermarker, convenience shop and restaurant

5. Aquatic products and food fresh preservation

6. Chemical and concrete projects

* Power supply: 380V/ 50Hz(60Hz)/ 3P; 220V(230V)/ 50Hz/ 1P; 220V/ 60Hz/3P(1P); 415V/50Hz/3P; 440V/60Hz/3P.

* Standard conditions: water temperature: 25℃;ambient temperature: 45℃;condensing temperature: 40℃.

* Ice making capacity would be changed depending on installation place, refrigerator’s freezing capability, or surrounding usage environment such as outside temperature.

Application

What is tube ice and what is its advantage?

Tube ice is cylindrical shaped ice with hollow core, and it is powderless. Compared with flake ice, tube ice exhibits longer melting time, so it is more suitable for cooling things in uninsulated environment. What is more, it is solid and less prone to generate ice lumps, making it suitable for long distance delivery.

Why choose ICESNOW tube ice machine?

1. Our tube ice maker is constructed via innovative manufacturing technology, and its ice scraping surface is as smooth as a mirror. That has tremendously increased ice scraping efficiency and overall energy efficiency ratio.

2. Compared with competitors' evaporator, our ice machine evaporator is able to form uniform water membrane in a more effective way, and this is very helpful in making crystal ice tubes.

3. For our tube ice machine, its ice cutter could be easily dismantled or replaced as a whole, and its water reservoir adopts an open structure to facilitate cleaning and disinfection.

4. With an optimized structural design, this tube ice generator not only has simple structure and high reliability, but also fits for container transportation for overseas clients.

Advantages Of Tube Ice Machine

1. High reliability and low fault failure

80% components of the tube ice maker system are world famous brand.Through decades of research and practice, it can run continuously without fault and keep good run and stable ice output even in ambient temperature 5°C-40°C.Special designed machine can even allow normal run in the most atrocious conditions(-5°C-+56°C)

2. Scientific design and advanced processing technique

Scientific design can also make the best ice making system according to customers actual demand, with world leading ice making technology and processing and testing equipments .Each part is processed with strict technique requirement and strictly tested before using.

3. Sanitary

Quality and sanitary tube ice maker .All parts contacting with water are made of stainless steel SUS304 or SUS316L and PE material .

4. With stable continuous running ,the tube ice maker realizes the running without energy wasting.Compared with orher ice making equipments, the ice maker boasts the advantages of compact structure, small area, low production cost,high refrigeration effect and low energy consumption.

5. Module design and simple maintenance

The ice maker has module design for simple maintenance on site. Tube ice maker can be installed inside a standard container, very suitable for frequent moving occasion.

6. PLC are adopted for tube ice maker to realize one-key operation.Several sets of large system in parallel connection can be centrally controlled with remote control interface.

FAQ

Q1. When can I get the price ?

A1:We usually offer the quotation within 2-3 work days for equipment and 5-10 work days for system after receiving your inquiry. For urgent offer, please contact with us for special.

Q2. What is the Trade Term?

A2: We accept Ex-work factory , FOB, CNF or CIF, as your requirement.

Q3. How long is our Production leading time?

A3: It depends on type of equipment.

For 1-3ton, about 20 days,

For 5-10ton, about 30 days,

Above 15ton, about 40-50 days

Q4. What is the Payment term?

A4: By 100% T/T before shipment or By L/C at sight.

Q5. During shipping, if there is a damage to products, how do you get replacement?

A5: Firstly, we should investigate the reason cause the damage. At the same time, we will claim for the insurance by ourselves or assist the buyer.

Secondly we will send the replacement to the buyer. The responsible person for above damage will take charge of the cost of the replacement.

Q6. What are your terms of packing?

A6: Packing: export worthy package suitable for container transportation.

Q7. Do you test all your goods before delivery?

A7: Yes, we have 100% test before delivery. We test about 3 days before delivery,

Q8. How do you make our business long-term and good relationship?

A8: our factory was established on 2003. Good quality and reliable service create good reputation among the customers. Many customers keep adopting our system in past 20 days extension of the business. Win-win business is our main task for the long-term cooperation.

Q9. What is your warranty?

A9: Warranty: 12months after commercial running or 18months from the date of shipment, subject to the earlier expiry.

Q10. Can we do our OEM logo?
A10:Yes, for the products with drawing supplied by you, we of course apply your logo
