ICESNOW 300kg/Day Flake Ice Machine

Short Description:

Certification: CE CERTIFICATE

Packaging Details: WOODEN PACKING

Delivery Time: 10 working days

Voltage:380v/50hz/3p

Material:Stainless Steel

Temperature Of Flake Ice:-5℃～-8℃

Ice Thickness:1.5mm-2.2mm

Water-feeding Pressure:0.1Mpa－0.6Mpa

Send email to us

Product Detail

Product Tags

Main Features:

1. Daily Capacity: 300kg/24 hrs

2. Machine power supply: 1P/220V/50HZ

3. The equipment can be used with stainless steel ice storage bins or polyurethane ice storage bins, and a wide range of accessories are available.

4. Whole processing is made by vertical lathe to ensure the precision up to 2 ounces;.

5. Cooling type: air cooling

6. Refrigerant gas: R22/R404A/R507

Product Decription:

1 .flake ice Evaporator Drum: Use Stainless Steel material or Carbon Steel Chrominum. The scratch-style of inside machine ensures constant running at the lowest power consumption.
2. Thermal insulation: foaming machine filling with imported polyurethane foam insulation. Better effect.
3. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.
4. Ice blade: made of SUS304 material seamless steel tube and formed through only one time process. It's durable.

5. Perfect in food cooling: Flake ice Is type of dry and crispy Ice, it hardly forms any shape edges. In food cooling process, this nature has made It the best material for cooling, it can reduce the possibility of damage to food to the lowest rate.

Product Specification:

Name	Technical Data
Ice production	300kg/24h
Refrigeration capacity	1676Kcal/h
Evaporating temp.	-20℃
Condensing Temp.	40℃
Ambient Temp.	35℃
Total Power	1.6kw
Refrigerant	R404A
Voltage	220V-50HZ
Dimension of ice bin	950mm×830mm×835mm
Dimension of flake ice machine	1050mm×680mm×655mm

Product Advantage:

1. Long history: Icesnow has 20 years of ice machine production and R&D experience

2. Easy operation: Fully automatic operation using PLC programmable control system, stable performance, easy operation of ice maker, one key to start, no person need monitor the ice machine

3. Pass the international CE, SGS, ISO9001 and other certification standards, the quality is reliable.

4. stable performance:The ice machine parts are selected from Demark of Danfoss, Copeland of America, Bitzer of Germany, Hanbel of Taiwan, and Korea PLC controllers of international famous

5.Simple maintenance and convenient moving
All our equipment is designed on the basis of modules, so its spot maintenance is quite simple. Once some of its parts needs replacing, it is easy for you to remove the old parts and install the new ones. Moreover while designing our equipment, we always take into full account how to convenience future moves to other construction sites.
